EV-Traffic installation manual
Don't have a trial software package but want to give it a shot?
Get your trial for free!
This manual will help you start your trial with EV-Traffic product
What you are going to do
Install software package
In order to run software as flawlessly as possible, there are some prerequisites for hardware and operating system
Get trial license key
When you finish the first step you will be able to actually run the software package. To do this you will need a license key generated specifically for chosen hardware that we will send you
Start your trial
As soon as you send us device key and we send you back trial license key, you are good to go with testing
Prerequisites
  • Hardware
    At least Intel® Core i3-8145U Processor (4M Cache, up to 3.90 GHz) with 4GB LPDDR3-2133 of RAM
  • Operating system
    Ubuntu 22.04
    Desktop or server version
  • Skills
    Basic experience with a Linux terminal is expected. Awareness of docker, ssh and scp linux tools.
Step by step
2. Prepare docker-compose.yml file
sudo apt-get update && sudo apt-get upgrade
curl -fsSL https://get.docker.com | sh
sudo usermod -aG docker $USER
newgrp docker
sudo curl -L "https://github.com/docker/compose/releases/download/1.29.2\
/docker-compose-$(uname -s)-$(uname -m)" -o /usr/local/bin/docker-compose
sudo chmod +x /usr/local/bin/docker-compose
sudo service docker restart
1. Docker-compose installation. Execute it line by line (not everything at once)
version: "3.9"
services:
ev_sensor:
image: ghcr.io/edge-vision/traffic:2023.1.1
container_name: ev_sensor
restart: unless-stopped
privileged: true
volumes:
- ./volumes1:/app/volumes
- /var/run/docker.sock:/var/run/docker.sock
- /dev/mem:/dev/mem
- /sys/devices/virtual/dmi/id:/sys/devices/virtual/dmi/id
ports:
- "5000:5000"
- "5050:5050" # Numbers must be the same as STREAMING_PORT
cap_add:
- SYS_TIME
environment:
CURR_ENV: production
STREAMING_PORT: "5050"
logging:
driver: "json-file"
options:
max-size: "100m"
max-file: "1"
All steps are performed on the target machine where system should be installed if not stated otherwise
3. Pull docker image from the Edge Vision Github repository
docker pull ghcr.io/edge-vision/traffic:2023.1.1
4. Make the first launch of the system to receive Initial token and Device Key
docker-compose up -d
Initial token will be shown only once at the first system launch. Be careful to not miss it
5. Extract and save Initial token and device key
docker-compose logs | grep '@@@'
6. Send DEVICE KEY to us and we will come back with the license key
Download file
